New Materials for Thin-Film Solar Panels
1. Zintl-phosphide (BaCd2P2)
– Researchers at Dartmouth College in the US identified BaCd2P2 as a highly promising absorber material through computational screening of around 40,000 inorganic materials.
– It has a suitable band gap (~1.45 eV), long carrier lifetime (up to 30 ns), and excellent stability in air and water, potentially lowering manufacturing costs due to reduced moisture sensitivity.
– BaCd2P2 could be used as a p-type absorber or intrinsic absorber in thin-film cells and represents a new class of Zintl AM2X2 solar absorbers that are stable and efficient, rivaling halide perovskites in nonradiative recombination rates.
– While not yet ready for commercial panels, it opens a new avenue for thin-film solar absorption materials.
2. Perovskites
– Perovskite materials are a major breakthrough in thin-film PV research, with demonstrated efficiencies surpassing silicon in tandem cells (over 30% efficiency).
– Advantages include low cost, ease of manufacturing (layering onto surfaces), high defect tolerance, and lightweight flexible panels.
– Oxford University research has demonstrated perovskite conversion efficiencies as high as 27%, with forecasts suggesting possible efficiencies above 45% in the future.
– Perovskites do not require rare earth elements, reducing cost and ethical sourcing concerns.
3. Organic Photovoltaics (OPV)
– OPV uses organic materials to replace silicon, providing very thin, lightweight, and flexible solar panels.
– Although current OPVs have lower efficiency (~18.2%) and shorter lifespans due to degradation, they are inexpensive to produce and can integrate into many building materials, including transparent surfaces.
– OPVs offer a promising area for cost reduction and novel applications, despite needing improvements in durability and efficiency.
Novel Fabrication Techniques and Materials
4. Printable Nanomaterial Inks for Ultralight Thin Films
– MIT researchers developed ultrathin, ultralight flexible solar cells made from printable semiconducting inks deposited using scalable printing methods such as slot-die coating and screen printing onto releasable substrates.
– These printed modules can be peeled off to form lightweight devices around 15 microns thick, enabling easy integration onto fabrics or other surfaces.
– Such thin-film cells produce up to 730 W/kg power density, about 18 times more power-per-kilogram than conventional panels, suitable for wearable power or rapid deployment in emergencies.
5. Microgroove Manufacturing with Earth-Abundant Materials
– UK-based company Power Roll has pioneered microgroove thin-film solar cells which are extremely thin (around one micrometer wide cells) and manufactured using roll-to-roll vacuum coating processes adapted from food packaging technologies.
– Their technology employs perovskites but is compatible with various absorber materials, emphasizing the flexibility to deploy earth-abundant, non-rare-earth materials with global availability.
– This approach supports flexible, lightweight applications such as building-integrated photovoltaics (BIPV) on facades, windows, or floating solar installations, overcoming load limitations of traditional panels.
Summary Table
| Material/Approach | Key Features | Advantages | Challenges/Status |
|---|---|---|---|
| Zintl-phosphide (BaCd2P2) | Stable, efficient absorber, band gap ~1.45 eV | Long carrier lifetime, stable in air/water | Early research stage, not commercial yet |
| Perovskites | High efficiency (27%+), flexible, lightweight | Low cost, no rare earths, high defect tolerance | Stability and scalability improving |
| Organic Photovoltaics (OPV) | Thin, flexible, cheap, organic materials | Integration into varied surfaces, low cost | Lower efficiency, faster degradation |
| Printable nanomaterial inks | Ultrathin, lightweight, printable layers | Scalable manufacturing, high power per weight | Early production prototypes |
| Microgroove roll-to-roll | Vacuum coated films on flexible substrates | Roll-to-roll manufacturing, earth-abundant materials | Commercial scaling underway |
In conclusion, the research focus for thin-film solar panels includes emerging stable inorganic absorbers like zintl-phosphides, advanced perovskite materials, organic photovoltaics, and novel fabrication methods using printable nanomaterial inks and microgroove-coated flexible films. These innovations aim to create lightweight, flexible, high-efficiency solar panels that can be integrated into diverse environments beyond traditional silicon panel constraints.
