Level 2 EV chargers are more efficient than Level 1 chargers primarily due to higher voltage and amperage, which enable significantly faster charging speeds. Here’s the breakdown:
1. Power Output
- Level 1: Operates on 120V AC, typically delivering 1.0–1.4 kW, adding 3–5 miles of range per hour.
- Level 2: Uses 240V AC, delivering 3.3–19.2 kW, adding 10–75 miles of range per hour.
2. Charging Speed
Level 2 chargers can be 6–19 times faster than Level 1, depending on power output and the vehicle’s charge acceptance rate:
- Low-end Level 2 (3.3 kW): ~11 miles/hour.
- Standard Level 2 (6.6–7.2 kW): 22–24 miles/hour.
- High-end Level 2 (19.2 kW): Up to 54 miles/hour (for compatible EVs).
3. Practical Use Cases
- Level 1: Best for occasional use or as a backup, requiring 40–50+ hours for an 80% charge on most EVs.
- Level 2: Ideal for daily charging, replenishing overnight or during work hours.
4. Efficiency Factors
- Voltage: 240V reduces energy loss compared to 120V over the same wire gauge, improving efficiency.
- Amperage: Higher current (24–80A vs. 12–16A for Level 1) enables faster energy transfer.
- Vehicle Compatibility: While most EVs cap Level 2 at 11–11.5 kW, newer models support up to 19.2 kW for optimal speed.
Comparison Table
| Feature | Level 1 Charger | Level 2 Charger |
|---|---|---|
| Voltage | 120V | 240V |
| Power Output | 1.0–1.4 kW | 3.3–19.2 kW |
| Range Added | 3–5 miles/hour | 10–75 miles/hour |
| Use Case | Emergency/backup charging | Daily/home/public charging |
Level 2’s higher power output directly translates to reduced charging time and greater practicality for regular EV use.
