The potential challenges and limitations of using a two-tank direct thermal energy storage (TES) system include the following:
- Thermal Efficiency and Response to Temperature Fluctuations: While the two-tank direct system generally provides better operational efficiency compared to some alternatives, it can still face efficiency reduction due to large fluctuations in the working fluid temperature entering the power cycle. For example, a study showed that one-tank TES systems had lower mean organic Rankine cycle (ORC) efficiency compared to two-tank TES due to poorer response to temperature variations, indicating that temperature stability is crucial for optimal performance.
- Material and Operational Challenges: The hot and cold tanks store the same heat transfer fluid (typically molten salts or thermal oils), which imposes requirements on fluid stability, corrosion resistance, and thermal reliability at high temperatures. These factors can lead to corrosion, maintenance challenges, and thermal stress on the storage tanks and piping. Molten salts, for instance, can cause corrosion and operational reliability issues if not properly managed.
- Stored Energy Density Limitations: The energy density of a two-tank TES system depends on the maximum operating temperature and the heat capacity of the storage fluid. Increasing stored energy density requires either higher temperature operation or fluids with better heat capacity, which may raise costs or technical complexity. The temperature drop across the turbine and heat capacity of the fluid are critical for energy density but are constrained by material limits and system design.
- Thermocline Layer Challenges: Although more related to thermocline TES systems, the two-tank direct system can still suffer from incomplete utilization of thermal stratification. Without proper management, thermal mixing can degrade the effective storage capacity over time. The thermal stratification or thermocline thickness can increase due to mixing and diffusion through charge-discharge cycles, reducing storage efficiency and capacity over time.
- Capital and Maintenance Costs: The system requires two large storage tanks and associated piping and pumps, which increase capital cost. Maintaining thermal insulation and preventing heat losses can also add to operational costs. Improvements in heat capacity and temperature operation are economically motivated but need to balance cost and technical feasibility.
- System Simplicity vs. Flexibility: While the two-tank direct design is simple and efficient, it may be less flexible when adapting to different fluids or operating conditions compared to indirect systems that use separate fluids for heat transfer and storage. This can limit material choices and operational scenarios.
In summary, the two-tank direct TES system is appealing for its simplicity and efficiency but faces challenges related to temperature stability, material durability, thermal losses, energy density constraints, and capital costs. These factors must be carefully managed to optimize performance and economic viability in concentrating solar power and other thermal storage applications.
