The main advantages of radial flow packed-bed thermal energy storage (TES) systems are centered around improved hydraulic performance and potentially enhanced efficiency compared to traditional axial flow designs. Key benefits include:
- Reduced Pressure Drop: Radial flow packed-bed TES exhibits significantly lower pressure drops because fluid flows radially outward from the center pipe to the vessel walls rather than axially through the entire bed. This reduces pumping power requirements and operational costs.
- Higher Charging Efficiency: Experimental studies have shown charging efficiency improvements, with radial flow prototypes achieving about 80% efficiency compared to 75% for axial flow systems in laboratory settings. This suggests better heat transfer dynamics during charging.
- Potential for Improved Exergetic Efficiency: The radial flow configuration aims to achieve higher exergetic efficiencies, with design efforts targeting above 95%, due to more uniform flow distribution and better thermal management.
- Material and Temperature Range Advantages: Like other packed-bed TES systems, radial flow designs benefit from inexpensive storage materials and can operate over a wide temperature range, making them suitable for renewable energy integration and industrial waste heat storage.
- Self-insulation and Design Flexibility: Radial flow systems can incorporate features such as metallic meshes and strategic flow channel designs that offer self-insulation effects and enable more uniform heat distribution across the packed bed.
- Trade-offs: Although radial flow can reduce pressure drop and improve charging efficiencies, it may experience a slightly larger thermocline spread (thermal front degradation) which can impact thermal efficiency in some cases. However, certain radial flow aspect ratios can outperform axial flow on net efficiency when pressure drops are included in the analysis.
In summary, radial flow packed-bed TES systems offer lower hydraulic resistance and better charging efficiency, potentially leading to overall higher system efficiency and cost-effectiveness, especially when optimized designs are employed. These advantages make radial flow configurations a promising development for thermal energy storage in renewable energy and industrial applications.
