The main differences between Level 1, Level 2, and DC Fast Chargers (also known as Level 3) lie in the type of electrical current they use, their voltage, power output, and charging speed:
Level 1 Charging
- Uses a standard residential 120-volt AC outlet.
- The slowest charging option, typically adding about 4 miles of range per hour of charging.
- Can take 40–50+ hours to fully charge a battery electric vehicle (BEV) to 80% capacity.
- Suitable for overnight charging or for low daily driving needs.
- Convenient as it requires no special installation, just a standard household socket.
Level 2 Charging
- Uses 240 volts AC, similar to what is used for household appliances like dryers.
- Provides significantly faster charging, roughly 6 to 8 times faster than Level 1.
- Charging rates vary widely, generally between 6 kW to up to 19.2 kW, depending on amperage and the EV’s onboard charging capacity.
- Typically adds about 12 to 32 miles of range per hour of charging, with common examples like 6.6 kW yielding about 22 miles per hour and higher power units reaching up to 54 miles per hour.
- The most popular choice for home charging due to its balance between installation complexity and speed.
- Requires a dedicated charger and sometimes an electrical upgrade at home.
DC Fast Charging (Level 3)
- Uses direct current (DC) instead of alternating current (AC), allowing power to be fed directly to the battery.
- Operates at much higher voltages and current levels than Levels 1 and 2.
- Provides the fastest charging speeds, ranging from 25 kW up to 150 kW or more.
- Can add between 45 miles (at 25 kW) to 200 miles (at 150 kW) of driving range in just 30 minutes.
- Primarily found at public charging stations along highways and in commercial areas, ideal for quick top-ups during long trips.
- Not typically installed for home use due to cost and infrastructure requirements.
| Feature | Level 1 | Level 2 | DC Fast Charger (Level 3) |
|---|---|---|---|
| Voltage | 120 V AC | 240 V AC | High voltage DC |
| Power Output | ~1.4 kW | 6 kW to 19.2 kW | 25 kW to 150+ kW |
| Charging Speed (miles/hr) | ~4 | 12 to 32 (typical); up to 54 | 45 to 200 (in 30 minutes) |
| Typical Use | Home (slow charging) | Home and public (faster charging) | Public fast charging (quick top-ups) |
| Time to Full Charge | 40–50+ hours | Several hours | 30 minutes to an hour |
In summary, Level 1 chargers are slow and use standard outlets, Level 2 chargers are faster and require 240-volt outlets with dedicated equipment, and DC Fast Chargers provide rapid charging through specialized high-power stations using direct current.
