Battery Management System (BMS)

The Battery Management System (BMS) enhances performance and ensures functional safety for battery packs composed of multiple cells. Functional safety is critical as lithium-ion batteries can pose significant safety risks when operated outside their safe working range. After soldering and aging, our BMS product portfolio provides high measurement accuracy and supports ISO26262, achieving ASIL D functional safety levels.

We are committed to sustainable mobility and renewable grids, offering innovative BMS solutions that include a complete set of chipsets, universal software, and functional safety documentation for both wired and wireless BMS communication. Our reference designs help customers accelerate development and bring the latest BMS innovations to automotive and industrial applications.

Application Details

Interaction with applications:

• High Voltage BMS
• Low Voltage BMS
• Wireless BMS

Product Recommendations:

For High Voltage BMS, explore our product recommendations below:

• High Voltage Battery Management System (HVBMS)
• HVBMS Hardware Solutions
• Contact Driver HB2000: SPI Programmable 10A H-Bridge Brushed DC Motor Driver
• CAN Physical Layer TJA1145A: High-speed CAN transceiver with data rates up to 5 Mbit/s
• RTC PCA2131: Nano-power real-time clock for automotive applications with integrated quartz crystal
• System Basis Chip FS26: Functional safety system basis chip, low power, designed for ASIL D systems
• MCU S32K3: S32K3 automotive general-purpose microcontroller
• Pressure Sensor NBP8-9x: Highly integrated battery pressure monitoring sensor
• Load Driver MC12XS6: External automotive lighting multi-channel eXtreme switch
• Battery Gateway BMX6X02: Universal battery management system communication gateway
• MC33665A: Universal BMS communication TPL transceiver and CAN FD gateway
• TJA1057: High-Speed CAN Transceiver – Mantis Family
• TJA144x: Automotive CAN FD transceiver series
• Cell Controller MC33771C: 14-channel lithium-ion cell controller integrated circuit
• MC33775: 14-channel lithium-ion battery controller IC ASIL D
• MC33774: 18-channel lithium-ion battery controller IC ASIL D
• Battery Pack Monitor MC33777: Battery junction box monitoring IC
• MC33772C: 6-channel lithium-ion battery controller IC
• NFC Reader NCx3321: Front-end IC compliant with NFC Forum, featuring superior automotive RF performance
• NFC Tag NCx3310: NFC Forum compliant tag IC with I2C interface for automotive applications
• Temperature Sensor P3T1755DP: I3C/I²C bus precise digital temperature sensor with ±0.5°C accuracy
• P3T1750DP: I3C/I2C bus digital temperature sensor with ±1°C accuracy

Low Voltage BMS Product Recommendations:

• Intelligent Battery Sensor MM9Z1_638: Battery Sensor with CAN and LIN
• MCU S32K1: S32K1 automotive general-purpose microcontroller
• Battery Gateway MC33664: Isolated network high-speed transceiver
• Battery Cell Controller MC33772C: 6-channel lithium-ion battery controller IC
• Battery Cell Controller MC33771C: 14-channel lithium-ion battery cell controller integrated circuit

Wireless BMS Product Recommendations:

• Wireless Battery Management Systems
• Gateway BMA606X: Wireless battery management system link

Reference Designs

For the 800V Battery Management System (BMS), our reference design kit RD-HVBMSCT800BUN is available. This includes:

• HVBMS Reference Design Package RD-HVBMSCTBUN tailored for high voltage battery management systems.
• Hardware Reference Design HWRD-HVBMSCC for high voltage battery management systems based on CAN FD.
• Centralized Cell Monitoring Unit (CMU) RD33775ACNTEVB that supports ETPL communication.
• Battery Junction Box (BJB) reference design RD772BJBTPLEVB utilizing ETPL and MC33772C.
• Battery Management Unit (BMU) reference design with S32K344 RD-K344BMU.

Documentation

We provide a range of documents including:

• Product Briefs
• Manuals
• Data Sheets
• White Papers
