The use of HVAC systems in electric vehicles (EVs) has a significant impact on their driving range, especially depending on the outside temperature and the type of heating or cooling technology used.
Impact of Cooling (Air Conditioning)
- Running the AC in moderate temperatures (below about 85-90°F or 29-32°C) leads to relatively minor range reductions. For example, at 80°F, the range loss is about 2.8%, and at 90°F, it increases to around 5% across multiple EV models.
- However, in very high ambient temperatures (around 40°C/104°F), cooling the cabin along with key EV components can demand 5-6 kW of power, which could reduce the EV’s range by approximately 26-30%.
Impact of Heating
- Heating the cabin in cold weather has a more dramatic effect on range. Using traditional resistive heaters without heat pumps can reduce range by up to 50% in sub-freezing temperatures (below -10°C or 14°F), as heating requires significant electrical energy drawn from the battery.
- Heat pumps are a more efficient heating technology that can markedly improve cold-weather range. Studies show that EVs with heat pumps see only about an 8-10% reduction in range near 30°F (-1°C), compared to up to 26% increase in energy consumption with resistive heating.
- Some data examples include the BMW i3 losing 50% range with HVAC on in cold weather, versus a smaller 20% loss with HVAC off; the Chevy Bolt also lost 47% range with HVAC on compared to 10% loss with HVAC off in cold conditions.
Innovations to Mitigate HVAC Energy Impact
- Researchers are developing technologies such as a chemical heat pump combined with microwave energy (called an e-Thermal bank) that can store thermal energy more efficiently. This system aims to extend BEV range by up to 70% by reducing the energy lost to heating and cooling during extreme temperatures.
Summary
| HVAC Function | Temperature Range | Approximate Range Impact on EV |
|---|---|---|
| Air Conditioning | Moderate (below ~85°F/29°C) | Negligible to ~3-5% range loss |
| Air Conditioning | Very High (~40°C/104°F) | Up to 26-30% range loss |
| Resistive Heating | Cold (below -10°C/14°F) | Up to 50% range loss |
| Heat Pump Heating | Cold (~30°F/-1°C) | ~8-10% range loss |
In conclusion, HVAC systems can have a substantial impact on EV range, with heating in cold weather being the more critical factor. Efficient heating solutions like heat pumps can significantly reduce this range penalty. Cooling generally has a smaller impact unless in very hot climates. Advanced thermal energy storage technologies under development promise further improvements to range by mitigating HVAC energy demands.
