The energy density of hydrogen has a significant impact on its transportation costs due to how it influences the mode and efficiency of transport.
Energy Density and Transportation Modes
Hydrogen has a low volumetric energy density in its natural gaseous state, even when compressed. This low density means large volumes must be transported to carry significant amounts of energy, leading to higher transportation costs per unit of energy. Common methods include compressed gas in tube trailers, liquefied hydrogen in tankers, and pipelines.
- Compressed Gaseous Hydrogen: Transporting hydrogen as a compressed gas in tube trailers is relatively simple and involves lower capital expenses for equipment (trailers cost around $50,000–$100,000 each), but it is expensive on an operational cost basis. The cost ranges from about $0.1–1 USD/kg for distances up to 100 km and $1–2 USD/kg for 100–500 km, reflecting the inefficiency of transporting low energy density gas over significant distances. Delivery costs at fueling stations using tube trailers have been estimated around $8–$9.50/kg depending on scale.
- Liquefied Hydrogen: Liquefying hydrogen increases its energy density by about a factor of 8 compared to compressed gas, making it more suitable for transporting larger quantities over longer distances. However, liquefaction adds significant processing and capital costs, reflected in delivery costs of approximately $2.7–3.2/kg H₂. For long distances, liquefied hydrogen tends to be more cost-effective than compressed gas due to the higher density reducing transportation volumes and costs per unit energy.
- Pipelines: Pipeline transport offers the lowest cost per unit of hydrogen delivery over short to medium distances, especially when hydrogen is compressed rather than liquefied. Pipelines benefit from continuous transport and economies of scale, making them more cost-effective than truck transport for large volumes over shorter distances.
Impact of Energy Density on Cost
Because hydrogen’s low volumetric energy density requires bulky storage/transport, transportation costs are higher compared to liquid fuels with higher density. Increasing the hydrogen energy density (e.g., via liquefaction or chemical carriers) reduces transportation volume and cost per kg of hydrogen delivered, but at the expense of higher capital and energy input for processing.
Summary
| Transport Mode | Energy Density Effect | Approximate Cost Range (USD/kg H₂) | Distance Suitability |
|---|---|---|---|
| Compressed Gas (Tube Trailer) | Low energy density → higher volume, higher cost | $0.1–2 (depending on distance) | Short to medium distances |
| Liquefied Hydrogen | Higher density reduces volume and cost | $2.7–3.2 | Longer distances |
| Pipelines | Efficient for large volumes, compressed gas favorable | Lower than truck transport; cost-effective | Short to medium distances |
In conclusion, hydrogen’s low energy density in gaseous form drives up transportation costs by increasing volume and handling needs. Liquefaction or pipeline transport improves energy density per transport volume, lowering costs for longer distances and large volumes but requires higher upfront investment and energy consumption. This tradeoff strongly influences the choice of hydrogen transportation methods and their associated costs.
