Overview of Thermal Energy Storage Costs
- Molten Salt Systems: These are a common form of TES used in concentrated solar power plants. The cost can range around $350/kWh for a 10 MW-scale system with a 10% internal rate of return (IRR), requiring about 13.5 c/kWh-th to operate effectively.
- Particle Thermal Energy Storage (TES): This is a newer technology being explored for grid-scale applications. It can offer lower costs, potentially around $2/kWh-th, due to the use of low-cost silica sand and efficient containment methods.
- Global Average Costs for TES Systems: According to BloombergNEF, thermal energy storage can have an installed cost as low as $232/kWh globally, making it one of the most affordable long-duration energy storage technologies available today, especially for durations exceeding eight hours.
Factors Influencing Costs
- Scale: Larger systems tend to have lower costs per kWh due to economies of scale.
- Location: Costs can vary significantly based on geographical location, with countries like China offering favorable policies leading to lower costs.
- Technology Sophistication: Advanced technologies like high-efficiency power cycles can reduce costs and improve efficiency.
- Storage Media: The type and cost of the storage medium, such as molten salt or particulate matter, affect overall system cost.
Comparison with Other Storage Technologies
| Technology | Cost Range | Notes |
|---|---|---|
| Thermal Energy Storage | $232/kWh (global avg), $350/kWh (specific projects) | Molten salt and particle systems are prominent. |
| Compressed Air Storage | $293/kWh (global avg) | Costs are higher outside China due to lower adoption rates. |
| Lithium-Ion Batteries | $304/kWh (for 4-hour discharge) | Costs are falling due to economies of scale and improved technology. |
| Flow Batteries | Higher than thermal and compressed air | Still developing, especially in China. |
| Pumped Hydro Storage | Higher than CAES at long durations | Limited by geography but remains competitive at long durations. |
In summary, while thermal energy storage is cost-effective, its costs vary based on the specific technology used and scale of implementation. Particle TES systems show promisingly low costs, while molten salt systems are more established.
