How do solar trackers impact the overall cost of a solar energy system

Solar trackers significantly impact the overall cost of a solar energy system, primarily by increasing both upfront investment and maintenance expenses, but they can also affect cost-effectiveness depending on various factors.

Increased Upfront Costs

• Solar trackers add a substantial premium to solar system costs. For example, a typical 4 kW fixed ground-mounted system costs about $13,000, but adding a single-axis tracker can raise the cost to approximately $20,000, a 57% increase, while a dual-axis tracker can double the total cost to around $26,000.
• On a per-panel basis, tracking equipment can cost between $500 and over $1,000 per solar panel, making it a major contributor to system capital expenditure.
• Installation complexity, including extra site preparation like trenching and grading, adds to the initial costs, especially with trackers that have moving parts requiring structural considerations.

Maintenance and Operational Costs

• Solar trackers include moving mechanical components, leading to higher maintenance needs compared to fixed systems, which have few or no moving parts. This results in ongoing operational expenses to maintain optimal performance and reliability.
• The potential for mechanical failures and the need for regular inspection, lubrication, and repairs increase lifecycle costs relative to fixed panel arrays.

Impact on Energy Production and Cost Savings

• Trackers increase energy output by orienting panels to follow the sun’s path, enhancing performance and potentially boosting electricity yield by up to 35% or more, especially with single-axis trackers.
• This increased energy generation can reduce the levelized cost of electricity (LCOE) for large, utility-scale solar projects by effectively producing more electricity without adding panels, improving the energy yield per dollar invested.
• Despite higher costs, trackers can be financially advantageous in certain contexts, such as locations with significant seasonal sun angle variations (e.g., higher latitudes) or where time-of-use electricity rates make producing power during peak demand more valuable.

Cost-Effectiveness and Payback Considerations

• For residential installations, trackers often are not cost-effective. It is usually cheaper to add more fixed solar panels than to invest in trackers, as the additional electricity generated by trackers does not proportionally offset their high added costs. For example, adding a dual-axis tracker may cost $15,000 extra but only increase annual savings by around $440, extending the payback period to nearly 20 years, whereas adding more panels for about $5,850 can achieve comparable energy output at a lower cost.
• Trackers tend to offer better value for commercial or utility-scale projects, where ground-mounted systems can benefit from higher yields and where economies of scale help offset costs.
• The economics depend strongly on location (solar irradiance and latitude), grid policies like net metering (affecting the value of excess energy), and the structure of electricity rates.

Summary Table of Cost Impact

In conclusion, solar trackers increase the overall cost of a solar energy system substantially, mainly due to expensive hardware and increased maintenance. While they improve energy yield and can reduce the levelized cost of energy in utility-scale projects, their high upfront cost often makes them less attractive for residential solar installations, where adding more panels is generally more cost-effective.
