Hongshun HK32F407 Empowers BMS, Leading New Breakthroughs in Battery Management

1. Market Size and Growth

With the rapid development of global new energy vehicles and energy storage systems, the market for Battery Management Systems (BMS) is continuously expanding. According to relevant data, it is expected that by 2025, the global BMS market will exceed 20 billion USD, with a compound annual growth rate of around 15%. In the field of new energy vehicles, with the accelerated transition to electric vehicles, production continues to rise, leading to increased demand for BMS, which is one of the core components. Additionally, in other application areas such as energy storage systems, consumer electronics, and industrial equipment, the requirements for battery safety, reliability, and performance are continuously increasing, further driving the growth of the BMS market.

2. Market Applications

• New Energy Vehicles: This is one of the main application areas for BMS. The system can monitor battery pack parameters such as voltage, current, and temperature in real-time, ensuring the battery operates within safe limits, prolonging battery life, and enhancing vehicle range and performance.
• Energy Storage Systems: In energy storage systems, BMS can precisely manage batteries, facilitating charge and discharge control and energy scheduling. This improves the efficiency and reliability of energy storage systems and ensures stable operation, playing a vital role in energy storage and supply.
• Consumer Electronics: In consumer electronics like smartphones, tablets, and laptops, BMS can accurately control the battery charging and discharging processes, preventing overcharging, deep discharging, and overheating issues, thus extending battery lifespan and providing users with a safer and more stable experience.
• Industrial Equipment: In various industrial devices such as power tools, automated guided vehicles, and production lines, BMS ensures the safe operation of batteries in complex industrial environments, providing reliable power support and maintaining operational efficiency.

3. Solution Overview

The Hongshun HK32F407 is a high-performance ARM Cortex-M4 core MCU with a main frequency of 168 MHz and up to 1MB Flash and 256KB SRAM. It possesses strong data processing and storage capabilities, meeting the complex computational and data storage needs of advanced BMS systems. The BMS solution based on the HK32F407 includes the following components:

• Main Control Unit: Centered around the HK32F407, it manages the entire BMS system, running various algorithms and control logic to achieve precise battery management.
• Battery Sampling Unit: Equipped with high-precision sampling circuits to collect real-time data on voltage, current, and temperature, which is then transmitted to the main control unit for processing and analysis.
• Protection and Control Unit: Executes protective functions against overcharging, deep discharging, overcurrent, and short circuits based on commands from the main control unit, ensuring safe battery operation.
• Communication Unit: Features multiple communication interfaces such as CAN, SPI, and I2C, allowing data exchange between the BMS system and external devices (like vehicle controllers, energy storage controllers, and host computers) for remote monitoring and management.
• Display Unit: Utilizes buttons and indicators to show battery status information (e.g., voltage, current, charge level, temperature), system operation status, and fault alarms, allowing users to easily understand the battery system’s condition and take appropriate actions.

4. Core Advantages of the Solution

• High Performance Computing Capability: With a frequency of 168 MHz and an integrated single-precision floating-point unit (FPU), the HK32F407 can quickly process substantial battery data and run complex BMS algorithms in real-time, improving accuracy and efficiency.
• Rich Peripheral Interfaces: It offers multiple communication interfaces and peripheral functions such as CAN, SPI, I2C, UART, USB OTG, and Ethernet, facilitating connections and communications with various sensors, actuators, and other devices, thus meeting integration needs for wider applications.
• High-Precision Sampling and Monitoring: Equipped with several 12-bit ADC channels, it achieves high-precision sampling and monitoring of battery parameters, providing reliable data for accurate battery state evaluation and control.
• Robust Safety and Protection Features: The built-in hardware encryption modules, including AES256 and TRNG, secure battery and communication data against leakage and tampering. It also includes comprehensive protective mechanisms for quick responses to battery anomalies.
• Low Power Design: Supports various low-power modes, such as sleep and stop modes, automatically switching based on BMS system status to reduce power consumption and extend battery life, making it particularly suitable for applications with strict power requirements.
• Wide Temperature Operating Range: Operates reliably in a temperature range of -40°C to 105°C, adapting to various harsh environmental conditions and ensuring performance and reliability in extreme temperatures.

Product System Block Diagram

The Hongshun HK32F407 series MCU specifications include:

• Core: ARM® Cortex®-M4 Core
• Maximum Clock Frequency: 168 MHz
• Temperature Range: -40°C to 105°C
• Voltage Range: Dual power domains: VDD from 1.8 V to 3.6 V; VBAT from 1.8 V to 3.6 V.
• Typical Operating Current: 18.04 mA at 168 MHz, 2.63 mA at 16 MHz (Run mode); 12.04 mA at 168 MHz, 2.08 mA at 16 MHz (Sleep mode); Stop mode varies.
• Memory: Up to 1 MB of Flash with code security protection, 8 KB CPU instruction cache, and various SRAM configurations.
• GPIO: Configurable for various functions with up to 114 GPIO pins depending on packaging.
• Data Communication Interfaces: Multiple USART, UART, SPI, I2C, CAN interfaces, and more.
• ADC/DAC: Integrated 12-bit ADCs and DACs for high-resolution data conversion.
