Pilot and Demonstration Projects
- A pilot-scale demonstration plant associated with Highview Power Storage and the University of Brighton successfully showcased the viability of LAES as an energy storage medium. The project demonstrated the benefits of cold recycle in improving cycle efficiency and provided valuable data for scaling up to commercial units. The plant uses air liquefaction and energy recovery via a Rankine cycle, with thermal energy storage enhancing overall efficiency.
Industry Integration Case Study
- Encord supported Sumitomo SHI FW in assessing the integration of their LAES technology in various markets. This case study analyzed the potential benefits of LAES for long-duration energy storage and its impact on reducing greenhouse gas emissions, highlighting practical deployment scenarios for LAES.
Academic and Economic Analysis
- Recent research by MIT and collaborators found that LAES could be the lowest-cost option for grid-scale energy storage, with a levelized cost of storage (LCOS) around $60 per MWh—roughly one-third the cost of lithium-ion batteries and half the cost of pumped hydro storage. Although not currently economically optimal for investment, LAES is seen as a promising solution for future grids requiring large-scale, secure storage.
Technological Advances and Efficiency Improvements
- Researchers from Korea have proposed an advanced standalone LAES system that incorporates oxy-fuel combustion and thermal energy generation using natural gas, significantly boosting power output and system versatility. Compared to a conventional 100 MW LAES, this system increased power generation by nearly 130%, while also providing substantial heating and cooling capacities. The round-trip efficiency was improved by 56.7% despite a slight reduction in exergy efficiency.
Efficiency Metrics
- State-of-the-art LAES systems can achieve round-trip efficiencies between 50-62% with well-designed parameters and existing technology, making them competitive for long-duration storage applications.
Summary Table of Key LAES Case Studies and Findings
| Case / Study | Scale/Type | Key Outcome / Performance |
|---|---|---|
| Highview Power pilot plant | Pilot-scale demonstration | Demonstrated viability, benefits of cold recycle; cycle efficiency improvement |
| Sumitomo SHI FW integration | Market assessment | Assessed benefits, GHG reduction potential |
| MIT research on LAES economics | Theoretical & modeling | LCOS ~$60/MWh, cost-competitive with other storage types |
| Korean advanced LAES system | 100 MW standalone system | 129.9% power increase, heating/cooling supply, 56.7% round-trip efficiency gain |
| General efficiency review | Various parametric designs | Round-trip efficiency: 50%-62% |
Conclusion
While full commercial deployment remains emerging, pilot plants and detailed case studies demonstrate that large-scale liquid air energy storage systems are technically viable and improving rapidly in efficiency and economic competitiveness. Innovative system designs, such as those using oxy-fuel combustion combined with cryogenic separation, further enhance their potential. LAES stands out as a promising solution for future grid-scale, long-duration energy storage needs.
