Example Projects

from serial import Serial
import time

# Connect robot
robot = Serial('COM3', 115200, timeout=1)
time.sleep(2)

def send_gcode(cmd):
    robot.write((cmd + '\n').encode())
    print(f"Sent: {cmd}")
    time.sleep(0.1)

def pick_place():
    """Simple pick and place demo"""

    # Object position
    object_x, object_y = 30, -20

    # Target position
    target_x, target_y = -40, 30

    # Safe height
    safe_z = -160
    pick_z = -200

    print("Starting pick and place...")

    # 1. Home
    send_gcode("G28")
    time.sleep(3)

    # 2. Move above object
    send_gcode(f"G0 X{object_x} Y{object_y} Z{safe_z}")
    time.sleep(2)

    # 3. Descend to pick height
    send_gcode(f"G0 Z{pick_z}")
    time.sleep(1)

    # 4. Suction
    send_gcode("M3")  # Pump ON
    send_gcode("M7")  # Valve ON
    time.sleep(0.5)

    # 5. Rise
    send_gcode(f"G0 Z{safe_z}")
    time.sleep(1)

    # 6. Move to target
    send_gcode(f"G0 X{target_x} Y{target_y}")
    time.sleep(2)

    # 7. Descend
    send_gcode(f"G0 Z{pick_z}")
    time.sleep(1)

    # 8. Release
    send_gcode("M9")  # Valve OFF
    time.sleep(0.3)

    # 9. Rise and turn off pump
    send_gcode(f"G0 Z{safe_z}")
    time.sleep(1)
    send_gcode("M5")  # Pump OFF

    print("Pick and place completed!")

# Run
pick_place()

# Close serial
robot.close()

import cv2
from ultralytics import YOLO
from serial import Serial
import time
import numpy as np

# Initialize
robot = Serial('COM3', 115200)
model = YOLO('yolov8n.pt')
cap = cv2.VideoCapture(0)
H = np.load('homography_matrix.npy')

# Sorting target positions
sort_bins = {
    'red': (-60, 40),
    'green': (0, 60),
    'blue': (60, 40)
}

def pixel_to_robot(px, py):
    """Convert pixel to robot coordinates"""
    point = np.array([[[px, py]]], dtype='float32')
    result = cv2.perspectiveTransform(point, H)
    return result[0][0][0], result[0][0][1]

def sort_object(color, x, y):
    """Pick and sort to corresponding position"""
    target_x, target_y = sort_bins[color]

    robot.write(b'G28\n')
    time.sleep(2)

    # Pick
    robot.write(f'G0 X{x:.1f} Y{y:.1f} Z-160\n'.encode())
    time.sleep(1)
    robot.write(b'G0 Z-200\n')
    robot.write(b'M3\n')
    robot.write(b'M7\n')
    time.sleep(0.5)
    robot.write(b'G0 Z-160\n')

    # Place
    robot.write(f'G0 X{target_x} Y{target_y}\n'.encode())
    time.sleep(1)
    robot.write(b'G0 Z-200\n')
    robot.write(b'M9\n')
    time.sleep(0.3)
    robot.write(b'G0 Z-160\n')
    robot.write(b'M5\n')

# Main loop
print("Color sorting started...")
while True:
    ret, frame = cap.read()
    if not ret:
        break

    # Object detection
    results = model(frame)

    for r in results:
        boxes = r.boxes
        for box in boxes:
            # Get class and position
            cls = int(box.cls[0])
            x1, y1, x2, y2 = box.xyxy[0].tolist()
            cx, cy = int((x1 + x2) / 2), int((y1 + y2) / 2)

            # Identify color (by class ID)
            color_map = {0: 'red', 1: 'green', 2: 'blue'}
            if cls in color_map:
                color = color_map[cls]

                # Coordinate transform
                robot_x, robot_y = pixel_to_robot(cx, cy)

                # Execute sorting
                print(f"Sorting {color} object at ({robot_x:.1f}, {robot_y:.1f})")
                sort_object(color, robot_x, robot_y)

    # Display results
    annotated = results[0].plot()
    cv2.imshow('Color Sorting', annotated)

    if cv2.waitKey(1) & 0xFF == ord('q'):
        break

cap.release()
cv2.destroyAllWindows()
robot.close()

def predict_position(current_x, current_y, velocity, delay):
    """
    Predict object future position

    Args:
        current_x, current_y: Current position
        velocity: Conveyor speed (mm/s)
        delay: Robot response delay (s)

    Returns:
        predicted_x, predicted_y: Predicted position
    """
    displacement = velocity * delay
    predicted_x = current_x + displacement
    predicted_y = current_y  # Assuming X-axis only movement

    return predicted_x, predicted_y

// File: esp32/gripper.cpp
#include

Servo gripper;
#define GRIPPER_PIN 16

void setup() {
    gripper.attach(GRIPPER_PIN);
    gripper.write(90);  // Initial position (open)
}

// M7: Close
void gripperClose() {
    gripper.write(30);  // Close angle
}

// M9: Open
void gripperOpen() {
    gripper.write(90);  // Open angle
}
